Shoring for heavy pours
A grid of verticals carries the wet concrete to the ground. Ledgers tie the grid in both directions and braces stop it swaying.
Scroll to see how it is built · drag to turn it round
- Home
- Products
- Scaffolding & Shoring
- Allshore Shoring System
Allshore Shoring System
Allshore is our Ringlock shoring for heavy slabs and decks: 65 mm verticals in YST 310 steel in the 10 T load class, tied in both directions and braced on every face.
Built to your size
Grid, height and jack travel follow your slab.
Verticals come in 5 lengths from 1 m to 3 m. The grid spacing is set by the ledger length you order. The model shows a table of 2 by 2 bays at 1.5 m, 3 m high, under beams and a plywood soffit.
- 65 x 3.2 mm
- vertical, diameter and wall
- 10 T
- load class
- 500 mm
- rosette spacing
- YST 310
- steel grade
Explore the model
How it is built.
Scroll: the camera moves to each part in turn and ends on the exploded view. Drag to turn it round yourself.
Loading model
0%
02 / 08
65 mm verticals
The verticals are 65 mm pipe, 3.2 mm thick, in YST 310 steel. The larger pipe gives the strength and stiffness that shoring needs.
- 1000 mm: 2 rosettes
- 1500 mm: 3 rosettes
- 2000 mm: 4 rosettes
- 2500 mm: 5 rosettes
- 3000 mm: 6 rosettes
How is it possible at Allmarc?
Used here for: 65 mm verticals
- 4 kW
- Tubes and sections up to 250 dia
- Automatic loading
03 / 08
Rosettes
Laser-cut rosettes are welded every 500 mm by robot, so every vertical is the same.
How is it possible at Allmarc?
Used here for: Rosettes
- Three-phase robotic MIG
- Automatic special-purpose welding machines
04 / 08
Ledgers and wedges
Ledgers are 48.3 mm pipe with investment-cast connectors. A captive wedge locks each end with one hammer blow.
05 / 08
Braces on every face
Diagonal braces on all 4 faces carry sideways load to the ground.
06 / 08
Base jacks and U-head jacks
Base jacks take up uneven ground. U-head jacks at the top carry the primary beams and set the soffit level.
07 / 08
What it carries
Primary beams sit in the U-heads, secondary beams cross them, and the plywood soffit goes on top.
08 / 08
Every component
Verticals, rosettes, ledgers, wedges, braces and jacks.
