Double-layer space frames for long-span roofs and covers: ball nodes, chords and web diagonals, made in our works for oil & gas, the metal industry and cement, and for power, logistics and public buildings. About 10,000 T a year.
Scroll: the camera moves to each part in turn and ends on the exploded view. Drag to turn it round yourself.
01 / 07
A space frame covers a stockpile, a plant floor or a terminal in one span. Two layers of tubes, tied by diagonals through ball nodes, act as one stiff shell.
Scroll to see how it is built · drag to turn it round
02 / 07
Every node is drilled and tapped on CNC for each member that meets it, at its exact angle, so the grid closes without forcing.
03 / 07
Tubes are cut to length and end cones welded on, then galvanised or painted. Each one is marked for its place in the grid.
Used here for: Chords
04 / 07
Diagonals tie the two layers together, so the frame carries load as a shell rather than as separate beams.
05 / 07
Bearings along the eaves let the frame move with temperature without loading the columns.
06 / 07
Sheeting goes on over the top chords; here it is shown on one bay so the frame stays visible.
07 / 07
Oil & gas: shelters and plant roofs. Metal industry: long-span plant sheds. Cement: stockpile and clinker storage covers. Also power plant coal yards, warehouses and logistics hubs, and canopies for terminals, toll plazas and stadia.
We fabricate to your drawings and prove the fit in our own bay before anything ships. Open any line for the detail.
