Refinery Process Structures

01 / 08

A process structure, as we build it

Bays, levels and loads follow your plot plan and equipment list; this model is one example with 3 levels. What we show is how the steel is made and checked.

Scroll to see how it is built · drag to turn it round

02 / 08

Columns

H-section columns cut, end-milled and drilled so splices and base plates bolt up square.

How is it possible at Allmarc?

Robotic H-beam cutting and bevelling cellBeams up to 1,000 x 500 mm

Used here for: Columns

• Beams up to 1,000 x 500 mm
• 12 m long, 50 mm thick
• Hypertherm XPR 300

All our machinery

SKDX1030 CNC end-face millingMills beam and column ends square for bolted splices

Used here for: Columns

• Mills beam and column ends square for bolted splices

All our machinery

03 / 08

Floor beams at every level

Main and secondary beams drilled on 3 faces in one pass, so every connection lines up on site.

How is it possible at Allmarc?

Kotec newRun10DX CNC beam drilling lineH-beams up to 1,000 x 500 mm

Used here for: Floor beams at every level

Heavy profiles that need precise holes, where plasma cannot do the job: the lower structure and panel borders of a ground flare, and every bolted PEB and multi-storey frame.

• H-beams up to 1,000 x 500 mm
• Drills 3 faces in one pass
• Channels, angles and box sections

All our machinery

04 / 08

Bracing

Bracing in the end bays takes wind and seismic load to the foundations; gussets are cut on the laser.

How is it possible at Allmarc?

HSG 12 kW fibre laser12 kW

Used here for: Bracing

• 12 kW
• Cuts up to 40 mm
• 2,500 x 8,000 mm bed

All our machinery

05 / 08

Floors and edges

Grating panels cut round every equipment opening, with handrails and toe boards on all open edges.

How is it possible at Allmarc?

Grip-Strut walkway automation linePunching, embossing, edge bending, shearing

Used here for: Floors and edges

• Punching, embossing, edge bending, shearing
• Single-piece planks up to 8 m

All our machinery

06 / 08

Stair tower

Switchback flights and half landings on their own frame, outside the process area.

07 / 08

Around your equipment

The drums, exchangers and piping are yours. The openings, supports and access around them are ours.

08 / 08

A kit of parts

Columns, beams, bracing, floors and stairs: every member numbered, match-marked and packed in erection sequence.
